ZK-760 Fully Automatic Box Folding Machine adopts servo control system, programmable PLC program control system and man-machine interface control system to realize the one-time forming of box. The structure is compact, the operation is simple, and the production efficiency is high. Mainly suitable for box forming of packaging materials such as 250-450g ivory board and kraft paper. It is widely used in high-end paper box packaging in cosmetics, knitwear, baked food, toys, fruits, daily necessities, medicine and other industries.
Features
Open design of the forming part; convenient adjustment, compact and reasonable structure, stable performance, easy to understand and operate.
When the cardboard is added, the cardboard can automatically fed, and the continuous operations of cardboard feeding, folding, folding in, forming and come out box are completed at one time.
Using PLC programmable controller, encoder and photoelectric switch, air source detection and operation system, touch screen man-machine interface, implement the whole process automation of the box forming of the world cover.
Automatic fault diagnosis function.
Infrared safety protection system to ensure the safety of personnel operation.
Quick mold change adjustment device.
Note
The stanadard size of M value is 15mm,larger the box size ,the larger the M value.
The limit size will change due to the special material of the cardboard.
The company does not provide air compressors.
Due to continuous innovation in product design, the above data is for reference only; subject to change without notice.
Box Craft Drawing
